部件系统
|Components systems
导轨
|
MONORAIL
1.
偏心销（加载预应力）
2.
锁紧螺母
3.
偏心销的标记
4.
润滑系统的润滑油加注点
直应块轨将
4
应上该
,
处间导
2
应）心设润等导上该
载这承系
3
、心设在洁使的
度动位螺号润到可在游要就提必作（安有系的
润压线承系
4
成导轴标度任型块轴（安型块的
1
Eccentric pin (preload setting)
2
Lock nut
3
Mark for eccentric pin
4
Point for lubrication system
Each slide has 4 bearings, two of these bearings are
eccentric adjustable (see eccentricmarks pos. 3).
The preload setting can be done very easily by using
standard tools.
Lubrication can be obtained by felt wipers at pos. 4.
统行免紧
System description
可通过
www .winkel .de
网站下载二维
/
三维
CAD
图纸
CAD download in 2D/3D at
