General advices
Setting of the sliders
For systems, the rails will be deliveredwith sliders which are
preloaded in the rails.
When supplied separately, the preload must be set by the
user.
Preload setting procedure:
1. Assure that the raceways are clean.
2. Insert the slider into the rail. Press the felt slips
together when putting them into the rail.
3. Position the slider at one end of the rail.
4. For setting the preload, please use a combination
wrench and amid size screwdriver.
5. Each slider has 4 bearings, 2 of them, which aremarked,
are eccentric adjustable. With the eccentric adjustable
bearings the preload can be set.
6. Open the lock nut with the combinationwrench and
set thepreloadwith the screwdriver on theeccentricbolt.
Only a small preload is needed.
7. The eccentric bearings should be set with a preload
so that the slider runs without any clearance through the
whole raceway. High preload setting should be avoided!
High preload setting increase friction and force to
the bearingwhich reduces the lifetime!
8. Move the slider along the rail to verify thepreload setting.
Themovement should be smooth and at no point should
there be any clearance in the rail.
9. After setting the preload, fasten the lock nut while
holding theeccentricpinonpositionwith the screwdriver.
