158
L
max
= 12 m
L
max
= 12 m
L
max
= 12 m
标准型
Standard
2NbV
113.012.000
m
20.9 kg/m
A
26.6 cm
2
lx
492.7 cm
4
Wx
81.2 cm
3
ly
37.9 cm
4
Wy
14.8 cm
3
ey
1.5 cm
标准型
Standard
1NbV
113.011.000
m
14.8 kg/m
A
18.8 cm
2
lx
272.9 cm
4
Wx
52.9 cm
3
ly
27.3 cm
4
Wy
10.9 cm
3
ey
1.5 cm
m
10.5 kg/m
A
13.4 cm
2
lx
136.6 cm
4
Wx
31.6 cm
3
ly
15.4 cm
4
Wy
6.7 cm
3
ey
1.3 cm
标准型
Standard
0NbV
113.010.000
装配导轨
所有导轨都由优质钢
S450 J2
制成，最大长度
=12
米
新型
NbV
系列载荷量高
对我们的
WINKEL
轴承系统，本公司都以固定的长度
现货供应所有导轨
可根据要求提供良好直线度、喷砂处理的导轨
可按客户提供的图纸要求加工导轨
Fitting profiles
All profiles aremade from high-quality steel
S450 J2mod. L
max
= 12m
Higher load capacitywith newNbV-series
To ourWINKELBearing systemwe deliver all
profiles in fixed lengths, immediately from stock
All profiles are available in fine straightened
style and sandblasted on request
Machined profiles according to customer
drawings on request
部件号：
Article no.
部件号：
Article no.
部件号：
Article no.
注意：良好直线度的导轨，每米偏差±
0.3mm
，标准导轨每米偏差±
1.0mm
。
Notice: Standard profiles are generally sandblasted.
The straightness for fine straightenedprofiles is ±0.3mmpermeter. Standard±1.0mmpermeter.
