I-profilesNbV
All profiles aremade from high-quality steel
S450 J2mod. L
max
= 12m
Higher load capacitywith newNbV-series
Profiles not sandblasted
To ourWINKEL Bearing systemwe deliver all
profiles in fixed lengths, immediately from stock
All profiles are available in fine straightened
style and sandblasted on request (± 0,3mm per meter)
Machined profiles according to customer
drawings on request
以或许两线抗通一径的可向所统密列特
0.3mm
向要标的可所统密列特
1.0mm.
Notice: The straightness for fine straightenedprofiles is ±0,3mmpermeter. Standard±1,0permeter
