334
SLE - 2
重载荷线性系统
|Heavy load-linear-systems
多轴装置
|
Multi-axis-units
导重驱形齿装
号秒米
SLE –2
大轴平，齿 装或机精大硬，齿装
技术特格米
量克荷米 传竖
1000
置千
行型米 块带传向
2
载
/
速
钢规传向
2
载
/
速
线Ê格误件米±
1.0
业载
达直米 传向
30
载
水根据要求提供差长轮的用和
优点米
竖量克荷轨竖行型应竖较型
导重模例度水承受竖，量克荷
简单轮用和度差低轮设计成本
良好轮防尘轨防污格
无需过多轮保养
交货时间短
Steel-linear-unit
Type SLE - 2
with rack and pinion drive or timing belt drive
Technical characteristics:
Load capacity: max. 1000 kg
Speed:
max. 2m/sec horizontal
max. 2m/sec vertical
Repeatability: ± 1.0mm
Stroke:
max. 30m
Longer axismodules on request.
The advantages:
high load capacity, speed and precision
high dynamic load capacity achieved by steel profiles
simple, modular and less costly design
better resistant against dust and dirt
lessmaintenance needed
short delivery times
质滑轴模例 或机精
大硬，
Hardened racks or
timing belt drive
坚固轮管状导零复
Rigid tubular
element in steel
水调节
WINKEL
的承组复
JT
With adjustableWINKELBearingUnit JT.
WINKEL
较密导模例
WINKEL precision
steel profiles
拖链
Energy chain
