267
ca. 2100mm
ca. 4800mm
ca. 120mm
ca.
765mm
ca. 1800mm
No bumper required.
With integrated
security brake.
15 S+R
WINKEL-S+R
Comparison standard S+RMachine up to 15m andNEWWINKEL-S+R
2X50
5 /
2
6 /
3 /
2
3 /
60
Load capacity:
2 x 50 kg
Acceleration horizontal: 5m/ sec
2
Speed horizontal:
6m/ sec
Acceleration vertical:
3m/ sec
2
Speed vertical:
3m/ sec
Advantages:
Lifting and driving - the non-slip drive solutionwith
positive, interlocked power transmission.
Synchronized by using cardan shaft
Easy installation, increased rigidity, increased lifetime
of track rollers
Innovative load device
Reduced clearance in between boxes of approx.
60mm. More available rack space
Double reach stacking of boxes
Independent working security brake.
No hydraulic buffers required
More available rack space
|Heavy load-linear-systems
|
Lift systems
WINKEL-S+R
AdvantagesWINKEL-S+R:
Compact design, formore available rack space
Higher dynamics achieved bymechanical
noitasinorhcnys
