部件系统
|Components systems
WINKEL
轴承
|
WINKEL Bearings
概述
规格
对于轴承和导轨的规格，应确认最大允许的静承载力
F[N]
max. stat.
参见第
20
页
润滑
我们
WINKEL
轴承全部是滚柱型，在非稳定运行状况下有
一个轴终身润滑。凭借我们多年的经验，我们确保对一般
的应用而言，在非稳定使用情况下无损轴承的使用寿命。
在诸如仓库以及厂房的应用中，仅需在表面喷一些商业润
滑油就足够了。另外每
6
个月定期进行润滑。
从
4.055
到
4.063
的
WINKEL
轴承可重复润滑
,
可延长轴承的
使用寿命。一般来讲，我们采用
M6
螺纹塞封闭重复润滑
孔。我们发运的轴承都没有润滑油嘴。
在一些特殊的使用环境中，诸如在有尘、有污物、潮湿、
户外、超过
40
度的高温、载荷变化频繁（持续运行）以
及重载荷的情况下，应每个月对轴承做至少一次润滑。对
此，我们建议您采用我们的润滑系统
WINKEL Combi-Lub 1.
使用
在直径小于
100mm
的
WINKEL
轴承上进行焊接工作时
,
必须
将所有轴承的零件拆下。
重装轴承后
,
或者进行调试后，前边的螺丝应使用乐泰胶
水（
LOCITITE
）固定。
为避免焊接结合处破裂，进行焊接作业时，请采用非合金
钢焊条和焊条芯。
例如：采用欧盟统一标准
499
规定的焊条芯：
E425B42H10
。
例如：采用欧盟统一标准
758
规定的焊条芯
T424BC3H5/7424B
M3H5
。
大型
WINKEL
轴承应焊接在螺栓的两侧。
导轨上的导槽应涂少许润滑油，不能刷油漆。
特殊设计
型号（
PR
）
4.072(P)
到（
PR
）
4.080(P)
的
WINKEL
轴承，有专
门的螺栓。
系统解决方案
我们根据客户的需求设计制造完整的升降
-
输送装置。采
用
CAD
以及先进的技术进行设计生产，确保提供输送和自动
化领域的完整且灵活的解决方案。
CAD
下载
可通过我们的网站
下载
.
公差
所有不规格的尺寸，请参考
ISO 2768 –M.
General advice
Dimensions
For the dimension of bearing and profile, themaximum
allowable load F [N] max. stat. should be confirmed.
See page 20.
Relubrication
OurWinkel bearings are full complement cylindrical
rollers which are lifetime lubricated for one shift and
unsteady operation. Due tomany years of experiencewe
can assure you that for these kinds of use therewill be
no reduction of lifetime at normal applications.
For applications such as for example inwarehouses and
machine halls a light surface conservationwith commer-
cial spray oil will be sufficient and in addition, a regular
relubrication every 6months.
For extension of life-time theWinkel bearings 4.054 up
to 4.063 are relubricateable. Generally, the relubrication
holes are closedwith threaded plugsM6. The bearings
are deliveredwithout grease nipple.
In case of special environmental conditions such as
dust, incur of dirt, moisture, outdoor operations, temper-
atures over 40 degrees, frequent load changes (continu-
ous operation) and heavy duty the bearings should be
relubricated at least one time per month. For this we
would recommend to you to use our lubrication system
Winkel Combi-Lub 1.
Working up
For welding operations onWINKEL Bearings with a
diameter less than 100mm, all bearing components
must be disassembled.
After the assembling of the bearings, or after the
adjusting operation, the front side screws should be
securedwith loctite.
To avoid cracks in thewelded joints please usewelding
electrodes and coredwire for unalloyed steel.
For example electrode: E 42 5 B 42H 10 according
DIN EN 499.
For example coredwire: T 42 4 BC 3H5/
7 42 4 BM 3H5 accordingDIN EN 758.
JumboWINKEL Bearings should bewelded on both
sides of the bolt.
The guideways in the profiles should be lightly greased
and not painted.
Special designs
Special bolts are available forWINKEL Bearings of
type (PR) 4.072 (P) to (PR) 4.080 (P).
System solutions
We construct andmanufacture complete lift- and
handling units according to customer needs.
Constructions withCAD and a progressive production
enables high flexibility in achieving complete solutions in
the field of handling systems and automation.
CADDownload
Via our webpage is available at:
Tolerances
For all not tolerated dimensions counts ISO 2768 - m
