142
部件系统
|
Components systems
WINKEL
轴承
|
WINKEL Bearings
连防上型滑合速
WINKEL
承。
:
Duralloy
®
-
温有
Duralloy
®
-
喷涂
Duralloy
®
-
喷涂
构静机我可坚涂（何米型超薄且我纯洁
轴金降小和型锌组音就构粘可我号，电机有和高温有举
除金降镁齿钛处额轴中大金降润不，
由速锌低速摄料
60
可处系轴要兰这可型举有甲个程其对
载础求形轴们酯于该橡标中大改变，因此型法有甲钢艺
组音高确保中大镀橡元装殊状齿涂可轴恒点，
Duralloy
®
喷涂的优点
:
硬度
/
磨损保护
Duralloy
®
轴面不由纯可至少为
99%
轴小统标，法有和轴涂
可据约为
1200HV
，举
EHD
适装系型锌延期置件等
2.800Mpa
，
粘度
载求润
Duralloy
®
面不轴粘合和具层分动组表型有和几乎
于高能从特有甲求形润脱落，
润滑性
/
低摩擦系数
Duralloy
®
轴组属们酯使锌面不高殊标静机几大表轴集极
根直型产生锈力囊，电些锈力囊又该举比任缺少锈力轴
我端状喷系殊标静铬油脂库，
此额型电机组属们酯又能构摩擦乙数显著子低，
抗腐蚀性
Duralloy
®
轴组属们酯高保护特有甲轴求形于受中大化学
齿敷械如上，与传运轴涂小相比型
Duralloy
®
有和于该开
裂，
高提链成种是荷本产品目录其轴特层
Duralloy
®
-
温有导轴
WINKEL
承。，
Corrosion protection forWINKEL
Bearings: Duralloy
®
-coating
TheDuralloy
®
-coating
The Duralloy
®
-coating is an extremly hard, precise, very thin
and ultrapuremetallic chromium layer, which is characterized
by an excellent adhesive. The plating can be deposited on all
types of metals, except Magnesium and Titanium.
Due to the low process temperature of under 60 °C no chan-
ges to the structureof thebasematerial occur duringplating,
this essiential advantage of the process ensures shape and
hardness stability for anymanufactures components.
Advantages of theDuralloy
®
-coating:
Hardness/Wear protection
The Duralloy
®
surface consist of at least 99% pure chrome.
The plating hardness is approximatly 1200 HV and the over-
run load under EHD-conditions reaches around 2.800Mpa.
Adherence
The bonding from the Duralloy
®
surface on the substrate is
frommolecular nature. It isnearly impossible that the coating
peels away from the groundmaterial.
Tribology/low friction coefficient
The special structureof theDURALLOY
®
surface forms acon-
verging gap geometry and enables the creation of pockets of
lubricant. The lubricant pockets also form an oil reservoir for
extreme conditions as for example where there is starved
lubrication.
Furthermore the special structure contributes the reduction
of the friction coefficient considerable.
Protection against corrosion
The special structure of Duralloy
®
protects the groundmate-
rial against chemical andmechanical corrosion. Compared to
conventional hard chrome coatings the Duralloy coating is
free of cracks.
AllWINKELBearings in this catalogueareavailable inDuralloy
®
-
armoloy coated version on request.
向度
Application areas
球承。
|
Ball bearings
号压：轴敷器零装
|
Highly stressedmachine parts
